APPLICATION
For the Oil & Gas industry. These cables are used for electricity supply in low voltage installation system. They are suitable for installation in indoors and outdoors, in cable ducts, under ground, in power and switching stations, local energy distributions, industrial plants and where aliphatic and aromatic hydrocarbon may be present or where require chemical and mechanical protections.
- Voltage Rating Uo/U: 0.6/1kV
- Temperature Rating: -20°C to +60°C
- Conductor: Class 1 Solid (RE) or Class 2 Stranded (RM) Copper
- Insulation: XLPE
- Inner Sheath: PVC
- Screen: Aluminum/Polyethylene tape
- Drain Wire: Tinned copper
- Inner Sheath: HDPE
- Intermediate Sheath: Polyamide
- Armour: Galvanized steel wires (Single core: aluminum wires)
- Outer Sheath: Special PVC
| NO OF CORES | CONDUCTOR | NOMINAL WEIGHT | NO OF CORES | CONDUCTOR | NOMINAL WEIGHT | ||
| CROSSSECTION mm2 | TYPE | kg/km | CROSSSECTION mm2 | TYPE | kg/km | ||
| 1 | 25 | RM | 619 | 4 | 2.5 | RE | 770 |
| 1 | 35 | RM | 732 | 4 | 2.5 | RM | 799 |
| 1 | 50 | RM | 891 | 4 | 4 | RE | 888 |
| 1 | 70 | RM | 1129 | 4 | 4 | RM | 1917 |
| 1 | 95 | RM | 1394 | 4 | 6 | RM | 1052 |
| 1 | 120 | RM | 1665 | 4 | 10 | RM | 1467 |
| 1 | 150 | RM | 1963 | 4 | 16 | RM | 1836 |
| 1 | 185 | RM | 2383 | 4 | 25 | RM | 2477 |
| 1 | 240 | RM | 2975 | 4 | 35 | RM | 3010 |
| 1 | 300 | RM | 3613 | 4 | 50 | RM | 3964 |
| 1 | 400 | RM | 4505 | 4 | 70 | RM | 5123 |
| 2 | 1.5 | RE | 511 | 5 | 1.5 | RE | 751 |
| 2 | 1.5 | RM | 525 | 5 | 1.5 | RM | 774 |
| 2 | 2.5 | RE | 661 | 5 | 2.5 | RE | 840 |
| 2 | 2.5 | RM | 682 | 5 | 2.5 | RM | 870 |
| 2 | 4 | RE | 740 | 5 | 4 | RE | 979 |
| 2 | 4 | RM | 766 | 5 | 4 | RM | 1019 |
| 2 | 6 | RM | 868 | 5 | 6 | RM | 1317 |
| 2 | 10 | RM | 1041 | 5 | 10 | RM | 1640 |
| 2 | 16 | RM | 1410 | 5 | 16 | RM | 2096 |
| 2 | 25 | RM | 1833 | 5 | 25 | RM | 2855 |
| 2 | 35 | RM | 2176 | 5 | 35 | RM | 3777 |
| 2 | 50 | RM | 2628 | 5 | 50 | RM | 4645 |
| 2 | 70 | RM | 3569 | 7 | 1.5 | RM | 797 |
| 2 | 95 | RM | 4354 | 7 | 2.5 | RM | 919 |
| 2 | 120 | RM | 5165 | 10 | 1.5 | RM | 1114 |
| 3 | 1.5 | RE | 636 | 10 | 2.5 | RM | 1287 |
| 3 | 1.5 | RM | 654 | 12 | 1.5 | RM | 1179 |
| 3 | 2.5 | RE | 703 | 12 | 2.5 | RM | 1371 |
| 3 | 2.5 | RM | 729 | 14 | 1.5 | RM | 1251 |
| 3 | 4 | RE | 805 | 14 | 2.5 | RM | 1475 |
| 3 | 4 | RM | 830 | 19 | 1.5 | RM | 1427 |
| 3 | 6 | RM | 951 | 19 | 2.5 | RM | 1724 |
| 3 | 10 | RM | 1291 | 24 | 1.5 | RM | 1678 |
| 3 | 16 | RM | 1590 | 24 | 2.5 | RM | 2050 |
| 3 | 25 | RM | 2097 | 27 | 1.5 | RM | 1776 |
| 3 | 35 | RM | 2533 | 27 | 2.5 | RM | 2154 |
| 3 | 50 | RM | 3347 | 30 | 1.5 | RM | 1884 |
| 3 | 70 | RM | 4255 | 30 | 2.5 | RM | 2305 |
| 3 | 95 | RM | 5265 | 37 | 1.5 | RM | 2099 |
| 4 | 1.5 | RE | 688 | 37 | 2.5 | RM | 2851 |
| 4 | 1.5 | RM | 712 | 37 | 2.5 | RM | 2851 |
